Single Phase (Reversible)

50GSC (50cm/20″)




  • Slimline design for optimum space utilization, permitting installation in equipment
  • A unique drain mechanism discourages the ingress of water and dust into the motor, resulting in excellent durability
  • The high-performance totally enclosed condenser motor contains a thermal protector which prevent the temperature of the motor from rising abnormally
  • Can be used over an ambient temperature range of -10 degree to +50 degree
  • Possible to install horizontally or vertically

Shutter (Optional)

  • 50GASC (50cm/20″)
Model:50GSC
RPM:960
Capacity (CFM):3608
Motor W:249
Motor Rating:240V / 50Hz
Motor Type:6 Pole Condenser
Noise Level (dB):47
Net Weight (kg):22.50
