Single Phase (Reversible)

35GSC (35cm/14″)




  • Slimline design for optimum space utilization, permitting installation in equipment
  • A unique drain mechanism discourages the ingress of water and dust into the motor, resulting in excellent durability
  • The high-performance totally enclosed condenser motor contains a thermal protector which prevent the temperature of the motor from rising abnormally
  • Can be used over an ambient temperature range of – 10ºC to + 50ºC
  • Possible to install horizontally or vertically

Shutter (Optional)

  • 35GASC (35cm/14″)
Model:35GSC
RPM:1420
Capacity (CFM):1506
Motor W:88
Motor Rating:240V / 50Hz
Motor Type:4 Pole Induction
Noise Level (dB):44
Net Weight (kg):10.50
