Single Phase (Reversible)
35GSC (35cm/14″)
- Slimline design for optimum space utilization, permitting installation in equipment
- A unique drain mechanism discourages the ingress of water and dust into the motor, resulting in excellent durability
- The high-performance totally enclosed condenser motor contains a thermal protector which prevent the temperature of the motor from rising abnormally
- Can be used over an ambient temperature range of – 10ºC to + 50ºC
- Possible to install horizontally or vertically
Shutter (Optional)
| Model | : | 35GSC |
| RPM | : | 1420 |
| Capacity (CFM) | : | 1506 |
| Motor W | : | 88 |
| Motor Rating | : | 240V / 50Hz |
| Motor Type | : | 4 Pole Induction |
| Noise Level (dB) | : | 44 |
| Net Weight (kg) | : | 10.50 |
