Three Phase (Reversible)
45GTC (45cm/18″)
- Slimline design for optimum space utilization, permitting installation in equipment
- A unique drain mechanism discourages the ingress of water and dust into the motor, resulting in excellent durability
- The high-performance totally enclosed condenser motor contains a thermal protector which prevent the temperature of the motor from rising abnormally
- Can be used over an ambient temperature range of -10ºC to + 50ºC
- Possible to install horizontally or vertically
Shutter (Optional)
Model | : | 45GTC |
RPM | : | 1450 |
Capacity (CFM) | : | 3249 |
Motor W | : | 220 |
Motor Rating | : | 415V / 50Hz |
Motor Type | : | 4 Pole Condenser |
Noise Level (dB) | : | 52 |
Net Weight (kg) | : | 18.5 |
