Three Phase (Reversible)

60GTC (60cm/24″)




  • Slimline design for optimum space utilization, permitting installation in equipment
  • A unique drain mechanism discourages the ingress of water and dust into the motor, resulting in excellent durability
  • The high-performance totally enclosed condenser motor contains a thermal protector which prevent the temperature of the motor from rising abnormally
  • Can be used over an ambient temperature range of -10ºC to + 50ºC
  • Possible to install horizontally or vertically

Shutter (Optional)

  • 60GASC (60cm/24″)
Model:60GTC
RPM:940
Capacity (CFM):5544
Motor W:310
Motor Rating:415V / 50Hz
Motor Type:6 Pole Condenser
Noise Level (dB):49
Net Weight (kg):34
