Three Phase (Reversible)
50GTC (50cm/20″)
- Slimline design for optimum space utilization, permitting installation in equipment
- A unique drain mechanism discourages the ingress of water and dust into the motor, resulting in excellent durability
- The high-performance totally enclosed condenser motor contains a thermal protector which prevent the temperature of the motor from rising abnormally
- Can be used over an ambient temperature range of -10ºC to + 50ºC
- Possible to install horizontally or vertically
Shutter (Optional)
| Model | : | 50GTC |
| RPM | : | 1400 |
| Capacity (CFM) | : | 4097 |
| Motor W | : | 320 |
| Motor Rating | : | 415V / 50Hz |
| Motor Type | : | 4 Pole Condenser |
| Noise Level (dB) | : | 54 |
| Net Weight (kg) | : | 28.5 |
