Single Phase (Reversible)

45GSC (45cm/18″)




  • Slimline design for optimum space utilization, permitting installation in equipment
  • A unique drain mechanism discourages the ingress of water and dust into the motor, resulting in excellent durability
  • The high-performance totally enclosed condenser motor contains a thermal protector which prevent the temperature of the motor from rising abnormally
  • Can be used over an ambient temperature range of -10 degree to +50 degree
  • Possible to install horizontally or vertically

Shutter (Optional)

  • 45GASC (45cm/18″)
Model:45GSC
RPM:1410
Capacity (CFM):3060
Motor W:227
Motor Rating:240V / 50Hz
Motor Type:4 Pole Condenser
Noise Level (dB):51
Net Weight (kg):19.00
